Input Power

230VAC+/- 10%

Frequency

50 ± 3 Hz.

Out Put

Single O/P

Line Regulation

Better than 0.05% for the Input variation of +/-10%

Load Regulation

Better than 0.05% from no Load to full load.

Static Regulation

±1%.

Mode

CC&C

Ripple Noise

Less than 1 mV rms

Protection

Short Circuit and Over load with buzzer

Meter

1Voltmeter & 1Ammeter (Digital)

Output Voltage

7 segment Display.

Output Current

7 Segment Display.

Power On

On/Off Power switch

Terminals

Extended Output Terminals 4mm BTI-15

Indication

Constant Voltage Indication.                                                      Constant current Indication.

Setting Voltage

Output voltage setting Coarse & Fine tuning

Setting Current

Current Limit Down setting.Current Limit Up setting.

Operating Temp.

0ºC to +40ºC.

Storage Temp.

0ºC to +70ºC.

Humidity

85% RH.
