Capacitance Meter
Product Details:
X
Product Description
Mextech Dt1503 Capacitance Meter
3 1/2 Digits LCD Display zero Adjustment Measures Range 200pf up to 20000 uf.
Features
- 9 ranges
- 26mm high digit
- 1999 counts max
- Unit symbol display
- Low battery indication
- Protective holster (rubber boot)
- Zero adjustment (manually)
- Capacitance: 200pF/2nF/20nF/200nF/20.5%), 20000 for reference
- Power: 6F22 (9V) x 1
Technical Specifications
| Range | Resolution | Max.displaying in the ranges | Measuring frequency | Accuracy | |
| 200pF | 0.1pF | 199.9pF | 800Hz | +(0.5%+1) | |
| 2nF | 1pF | 1.999nF | 800Hz | ||
| 20nF | 10pF | 19.99nF | 800Hz | ||
| 200nF | 100pF | 199.9nF | 800Hz | ||
| 2uF | 1000pF | 1.999uF | 800Hz | ||
| 20uF | 0.01uF | 19.99uF | 80Hz | ||
| 200uF | 0.1uF | 199.9uF | 8Hz | ||
| 2000uF | 1uF | 1999uF | 8Hz | +(2%+1) | |
| 20000uF | 10uF | 1999(10)uF | 8Hz | ||
Click here for more details
